Track plan at a glance
Name: Mississippi, Alabama, & Gulf
Scale: HO (1:87.1)
Size: 24 x 27 feet
Prototype: freelanced
Era: 1950s
Style: around-the-walls and peninsula
Mainline run: 47 feet
Minimum radius: 22″ main line, 18″ on spur tracks
Minimum turnout: no. 4
Maximum grade: none
Originally appeared in the April 2005 issue of Model Railroader.
