Track plan at a glance Name: Utah Belt Layout designer: Eric Brooman Scale: HO (1:87.1) Size: 22′-8″ x 39′-6″ Prototype: freelanced Period: the present Style: linear walkaround Mainline run: 173 feet Minimum radius: 39″ Minimum turnout: no. 6 Maximum grade: 1.5 percent Originally appeared in the 2006 issue of Great Model Railroads. Click here to […]
Name: Brandywine Valley RR Layout designer: Dil Huey Scale: HO (1:87.1) Size: 26 x 42 feet Prototype: Octoraro RR Locale: Southeastern Pennsylvania and parts of Delaware and Maryland Era: transition era to 1980s Style: multilevel walk-in Mainline run: 365 feet Minimum radius: 30″ Minimum turnout: Peco large radius Maximum grade: 2 percent Originally appeared in […]
Name: Canada Central Ry. Layout group: Montreal Railroad Modelers Association Scale: HO (1:87.1) Size: 37 x 123 feet Prototype: freelance Locale: Quebec and Ontario, some western landscapes Era: 1959 Style: walkaround Mainline run: 1,200 feet Minimum radius: 42″ (main), 36″ (branch) Minimum turnout: no. 6 Maximum grade: 2.2 percent Originally appeared in the October 2011 […]
Name: Bona Vista RR Layout designer: Gerry Leone Scale: HO (1:87.1) Size: 14′-6″ x 30′-0″ Prototype: freelance Locale: northern Wisconsin and Minnesota Era: 1953 Style: walkaround Mainline run: 200 feet Minimum radius: 30″ Minimum turnout: no. 6 (mainline), no. 5 (spurs) Maximum grade: 1 percent Originally appeared in the Great Model Railroads 2008. Click on […]
Name: Denver Union Terminal Layout designer: Frank Czubryt Scale: O (1:48) Size: 24 x 32 feet Prototype: freelance Locale: Denver to Palmer Lake, Colo. Period: 1980s to present Style: walk-in Mainline run: 96 feet Minimum radius: 48” Minimum turnout: no. 6 Maximum grade: 1 percent Originally appeared in the Great Model Railroads 2008. Click on […]
Name: Panhandle & Santa Fe Ry. Scale: HO (1:87.1) Size: 12′-7″ x 33′-0″ Prototype: Third District of the Atchison, Topeka & Santa Fe’s Plains Division Locale: Texas Panhandle, Amarillo to Clovis, N.M. Era: September 1955 Style: linear walkaround Mainline run: 102 feet Minimum radius: 29″ Minimum turnout: no. 6, no. 4 in Amarillo Switching District […]
Name: Southern Ry. Layout designer: Bob Lawson Scale: HO (1:87.1) Size: 24 x 30 feet Prototype: Southern Ry. Locale: central and eastern Kentucky Era: 1945 through the early 1950s Style: walk-in with one duckunder Mainline run: 425 feet Minimum radius: 30″ Minimum turnout: no. 8 with some no. 6 Maximum grade: 1.5 percent Originally appeared […]
Name: Ida Valley Ry. Layout designer: Bob Allen Scale: Large scale narrow gauge (1:35) Size: 21 x 51 feet Prototype: New Zealand Rys. Locale: Otago Province, South Island, New Zealand Era: 1955 to 1965 Style: walk-in Mainline run: 240 feet Minimum radius: 72″ Minimum turnout: Peco medium radius Maximum grade: 1.1 percent Originally appeared in […]
Name: New Mexico Division Layout designer: Bob Foltz Scale: HO (1:87.1) Size: 45′-7″ x 47′-8″ Prototype: Atchison, Topeka & Santa Fe Ry. Locale: Northern New Mexico Era: 1951 Style: walkaround Mainline run: 350 feet Minimum radius: 36″ (main), 30″ (all others), 26″ (narrow gauge) Minimum turnout: no. 6 Maximum grade: 1.5 percent (main), 3.2 percent […]
Track plan at a glance Name: Green Mountain Division of the Boston & Maine Layout designer: Don Janes Scale: HO (1:87.1) Size: 12′-8″ x 20′-0″ plus 12′-0″ x 30′-0″ addition Prototype: Boston & Maine, Central Vermont, and Rutland Locale: Vermont Era: 1950 to 1958 Style: Around the walls Mainline run: 120 feet (original), 70 feet […]
Layout designer: John Penca Scale: O Layout size: 17 x 29 feet Track type: Atlas O Minimum curve: O-54 Originally appeared in the September 2009 issue of Classic Toy Trains. Click on the link to download a PDF of this track plan. Track plan Schematic Parts list […]
Layout designer: Kent Johnson Scale: O Layout size: 12 x 25 feet Track type: GarGraves Minimum curve: O-54 Originally appeared in the July 2006 issue of Classic Toy Trains. Click on the link to download a PDF of this track plan. Track plan Schematic Parts list […]
