Track plan at a glance Name: Pike City Belt Line Scale: HO Size: 8 x 12 feet Style: shelf Minimum radius: 18″ Minimum turnout: Peco large radius Originally appeared in the September 1998 issue of Model Railroader. Also appeared in 102 Realistic Track Plans. Click on the link to download a PDF of this track […]
Track plan at a glance Name: Puffer Bridge Lines Scale: HO (1:87) Size: 8′-7″ x 19′-4½” Prototype: free-lance Period: early 1970s Style: around the walls Mainline run: 44 feet Minimum radius: 22″ Minimum turnout: no. 4 in yards; no. 6 on main line Maximum grade: less than ½ percent Originally appeared in the 2002 issue […]
Track plan at a glance Name: Reading Co. Scale: HO (1:87) Size: 2½ x 17½ feet (city scene) Theme: urban industrial switching Period: late 1930s, early 1940s Style: shelf with backdrop Minimum radius: 36″ (main line) Minimum turnout: no. 6 on main line; no. 4 for industrial sidings Originally appeared in the 2003 issue of […]
Track plan at a glance Name: Shamokin Valley Lines Scale: HO (1:87) Size: 48 x 60 feet Prototypes: the Pennsylvania, Reading, and Lehigh Valley RRs Period: 1950s Style: island with internal aisles Minimum radius: 48″ on main lines, 30″ on branch lines Minimum turnout: no. 6 Originally appeared in the Febraury 1999 issue of Model […]
Track plan at a glance Name: Sud Pacifico con Otros (Spanish for “Southern Pacific with Others”) Scale: HO and HOn3 Size: 12 x 22 feet Theme: Southern Pacific Era: early 1950s Style: around the walls Mainline run: approximately 100 feet Minimum radius: 36″ Minimum turnout: no. 6 Maximum grade: none Originally appeared in the 2002 […]
Track plan at a glance Name: Tehachapi Pass Scale: HO (1:87) Size: 15 x 16 feet Prototype: Union Pacific (former Southern Pacific); Burlington Northern Santa Fe (former Santa Fe) has trackage rights Period: present Style: around the walls, walk-in Minimum radius: 36″ Minimum turnout: no. 8 on main, no. 6 in yard Maximum grade: 2.5 […]
Track plan at a glance Name: The Eastern Loggers Scale: HO (1:87)- standard and 3-foot gauge Size: 10 x 15 feet (expanding to 10 x 20 feet) Theme: Pennsylvania lumber industry and railroading Period: 1915-1925, summer Style: loop, walkaround island Minimum turnout: no. 4 Maximum grade: about 6 percent Originally appeared in the 1998 issue […]
Track plan at a glance Name: Timber City & Northwestern Scale: HO Originally appeared in the 1997 issue of Great Model Railroads. Click here to download a PDF of this track plan […]
Track plan at a glance Name: Utah Colorado Western Scale: HO (1:87) Size: 28 x 33 feet Prototype: free-lance Period: 1967 Style: peninsula walkaround Minimum radii: 30″ on main line, 26″ on branch line Maximum grade: 1.5 percent Originally appeared in the May 1999 issue of Model Railroader. Click this link to download a PDF […]
Track plan at a glance Name: Walla Walla Valley Ry. Scale: HO (1:87) Size: 10 x 11 feet Prototype: Walla Walla Valley Ry. Period: 1968 Style: linear walkaround Mainline run: 24 feet Minimum radius: 15″ Minimum turnout: Peco medium radius Maximum grade: none Originally appeared in the 2005 issue of Great Model Railroads. Click here […]
Track plan at a glance Name: Waynesburg & Washington RR Scale: HO (1:87 standard gauge) Size: 17 x 18 feet Theme: Pennsylvania RR Period: summer 1957 Style: point to point with connection for continuous run Minimum radius: 18″ Minimum turnout: handlaid no. 6 with no. 4 in some yards Maximum grade: 2½ percent Originally appeared […]
Track plan at a glance Name: Western Route of the Boston & Maine Scale: HO (1:87) Size: 11 x 13 feet Theme: B&M with Maine Central interchange Period: late 1950s-early ’60s Style: center access with surrounding staging Mainline run: 67 feet (27 feet visible plus 40 feet in staging) Minimum radius: 31″ Minimum turnout: no. […]
