Track plan at a glanceName: Deer MountainScale: HO (1:87.1)Size: 4 x 8 feetPrototype: free-lancedPeriod: late-1940s to mid-1950sStyle: walkaroundMainline run: 20 feetMinimum radius: 18″Minimum turnout: no. 4Maximum grade: 0Originally appeared in the June 2004 issue of Model Railroader. Also appeared in 102 Realistic Track Plans.Click on the link to download a PDF of this track plan […]
Track plan at a glanceName: Dorrville BranchScale: HO (1:87.1)Size: 40″ x 60″Prototype: New York, New Haven & HartfordTheme: small-town freightPeriod: around 1960Style: tabletopMinimum radius: 18″Minimum turnout: no. 4Originally appeared in the September 2004 issue of Model Railroader. Also appeared in 102 Realistic Track Plans.Click on the link to download a PDF of this track plan […]
Track plan at a glanceName: Eaglecreek & NorthernScale: HO (1:87.1)Size: 7′-10″ x 14′-5″Prototype: freelancePeriod: autumn 1953Style: walk-inMainline run: 84 feetMinimum radius: 18″Minimum turnout: no. 6 (main line), and no. 4 (yards)Maximum grade: 3 percentOriginally appeared in the July 2005 issue of Model Railroader. Also appeared in 102 Realistic Track Plans.Click on the link to download […]
Track plan at a glanceName: L&S DivisionScale: HO (1:87.1)Size: 22 x 24 feetPrototype: Baltimore & Ohio RREra: 1954Style: walk-inMainline run: 735 feetMinimum radius: 36″Maximum grade: 2.5 percentOriginally appeared in the April 2004 issue of Model Railroader.Click on the link to download a PDF of this track plan […]
Track plan at a glanceName: George Sebastian-Coleman’s $500 layoutScale: HOSize: 4′-0″ x 6′-6″Minimum radius: 18″Originally appeared in the January 2004 issue of Model Railroader. Also appeared in 102 Realistic Track Plans. Click on the link to download a PDF of this track plan […]
Track plan at a glanceName: Spring Creek Lumber Co. and Greenbrier & Pocahontas Central RRScale: HO (1:87.1)Size: 23′-0″ x 25’0″Theme: Depression-era eastern logging operation and common carrier railroadPeriod: summer 1934Mainline run: 112 feetMinimum radius: 22″ main, 18″ sidingsMinimum turnout: no. 4Maximum grade: 5 percentOriginally appeared in the August 2005 issue of Model Railroader.Click on the […]
Track plan at a glanceName: Ohio SouthernScale: HO (1:87.1)Size: 22 x 28 feet (L shaped)Prototype: Detroit, Toledo & Ironton RRPeriod: early 1970sStyle: double deck with a helix connecting levelsMainline run: 220 feetMinimum radius: 30″Minimum turnout: no. 5Maximum grade: 2.8 percentOriginally appeared in the September 2005 issue of Model Railroader.Click on the link to download a […]
Track plan at a glanceName: Pennsylvania Division of the Maryland & Pennsylvania RRScale: HO (1:87.1)Size: 8′-8″ x 22′-0″Prototype: Ma & Pa RRPeriod: 1946Style: walkaround shelfMainline run: 97 feetMinimum radius: 17.25″Minimum turnout: no. 4Maximum grade: 2 percentOriginally appeared in the December 2005 issue of Model Railroader. Also appeared in 102 Realistic Track Plans. Click on the […]
Track plan at a glanceName: Ninigret Cove BranchScale: HO (1:87.1)Size: 15 x 11 feetPrototype: New York, New Haven & HartfordTheme: small-town freightPeriod: around 1960Style: L-shaped shelfMinimum radius: 38″ (scale 4″ superelevation)Minimum turnout: no. 6, no. 8 crossoversMaximum grade: 2 percent (on the lumber siding)Originally appeared in the September 2004 issue of Model Railroader. Also appeared […]
Track plan at a glanceName: Northern Timber Co.Scale: HO (1:87.1)Size: 10 x 16 feetPrototype: free-lancePeriod: 1935 to 1940Style: around-the-walls and peninsulaMinimum radius: 26″Minimum turnot: no. 4Maximum grade: 1.5 percentOriginally appeared in the September 2004 issue of Model Railroader.Click on the link to download a PDF of this track plan […]
Track plan at a glanceName: Ozark, Ouchita & Red RiverScale: HO (1:87.1)Size: 10 x 14 feetPrototype: free-lancedPeriod: 1940s-1950sStyle: walk-inMainline run: 39 feetMinimum radius: 24″Minimum turnout: no. 4Maximum grade: noneOriginally appeared in the April 2004 issue of Model Railroader. Also appeared in 102 Realistic Track Plans.Click on the link to download a PDF of this track […]
Track plan at a glanceName: Morton DivisionScale: HO (1:87.1)Size: 24 x 36 feetPrototype: Chicago & North Western Ry.Period: late 1950sStyle: linear, walkaroundMainline run: 38 feetMinimum radius: 24″Minimum turnout: no. 6Originally appeared in the September 2004 issue of Model Railroader.Click on the link to download a PDF of this track plan […]
