Track plan at a glance Name: Benedict & Wexford Scale: HO Size: 10 x 10 Minimum radius: 18″ Minimum turnout: no. 4 Maximum grade: 4 percent Originally appeared in the December 2000 issue of Model Railroader. Also appeared in 102 Realistic Track Plans. Click on the link to download a PDF of this track plan […]
Track plan at a glance Name: Bogg’s Landing & Trotwater RR Scale: HO (1:87) Size: 8 x 12 feet Theme: free-lance short line Period: 1930s Style: walk-in horseshoe Mainline run: 63 feet (72 feet with continuouss-run connection) Minimum radius: 18″ Minimum turnout: no. 4 Maximum grade: 4 percent Originally appeared in the June 2001 issue […]
Track plan at a glance Name: City Edge Scale: HO (1:87) Size: 24 x 40 feet Theme: fictional urban railroad based on locations in Chicago and St. Louis Era: 1950 to present day Style: around the walls Mainline run: 110 feet Minimum radius: 38″ on the main line and 22″ in the warehouse district Minimum […]
Track plan at a glance Name: Old Colony & South Shore RR Scale: HO (1:87.1) Size: 24′-6″ x 33′-6″ with an 8′-0″ x 16′-6″ staging area Prototype: Boston & Maine Period: 1920 to 1940 Style: walkaround Mainline run: 200 feet Minimum radius: 36″ Minimum turnout: no. 6 Maximum grade: 1 percent Originally appeared in the […]
Track plan at a glance Name: Crystal River District Scale: HO (1:87.1) Originally appeared in the July 2003 issue of Model Railroader. Click on the link to download a PDF of this trackplan […]
Track plan at a glance Name: Cunningham’s Gap in HO Scale: HO Size: 10 x 11 feet Minimum radius: 24″ Minimum turnout: no. 6 Originally appeared in the March 2003 issue of Model Railroader. Also appeared in 102 Realistic Track Plans. Click on the link to download a PDF of this track plan […]
Track plan at a glance Name: E&W Lines Scale: HO (1:87) Size: 20′-6″ x 27′-0″ Theme: free-lanced Pennsylvania RR branch line Period: 1950s Style: point-to-point around the walls with walk-in access Mainline run: 160 feet Minimum radius: main line 28″ Minimum turnout: main line no. 6, industries no. 4 Maximum grade: 2.5 percent Originally appeared […]
Track plan at a glance Name: Federal Street Scale: HO (1:87 with Proto:87 fine scale standards) Size: 2′-0″ x 11′-6″ Theme: industrial branch line Era: mid-1950s Style: shelf Originally appeared in the May 2003 issue of Model Railroader. Also appeared in 102 Realistic Track Plans. Click on the link to download a PDF of this […]
Track plan at a glanceName: Florida East Coast Ry. Key West ExtensionScale: HO (1:87)Size: 16 x 24 feet with a 2 x 11-foot staging areaPrototype: Florida East CoastPeriod: January 31, 1930Style: walkaround, point-to-pointMainline run: 510 feetMinimum radius: 30″Minimum turnout: no. 6Maximum grade: 2 percentOriginally appeared in the February 2001 issue of Model Railroader. Also appeared […]
Track plan at a glance Name: Fort Travis & Dayton Scale: HO (1:87) Size: 9½ x 19 feet Theme: industrial switching Period: mid-’50s Style: walk-in Mainline run: 58 feet Minimum radius: 24″ Minimum turnout: no. 6 Maximum grade: 2.1 percent (¼” per foot) Originally appeared in the November 2001 issue of Model Railroader. Click on […]
Track plan at a glanceName: Georgia Southern RRScale: HO (1:87)Size: 8 x 8 feet with center operating areaTheme: free-lance, fictitious subsidiary of the Georgia RR with branch linePeriod: summer 1957Style: two-lap oval with three-track staging yardMainline run: 32 feetMinimum radius: 24″ main line, 20″ through curved turnouts, 18″ on sidingsMinimum turnout: no. 5Maximum grade: 4 […]
Track plan at a glance Name: Glenwood & Black Creek Scale: HOn3 (1:87) Size: 16′-6″ x 33′-0″ Theme: western narrow gauge Period: 1880 to 1930 Style: double deck Mainline run: 240 feet Minimum radius: 24″ Minimum turnout: no. 6 Maximum grade: 2 percent main, 3 percent branch Originally appeared in the May 2000 issue of […]
