Name: Cumberland & Ohio Layout designer: Michael Tylick Scale: HO (1:87.1) Size: 4 x 8 feet Theme: coal mining Locale: Appalachian Mountains Era: variable (1900-1970) Style: island Mainline run: 20 feet Minimum radius: 15″ Minimum turnout: no. 4 Originally appeared in the January 2013 Model Railroader. Click on the link to download the PDF of […]
Name: Sundance Central Layout designer: Sundance Central modular railroad club Scale: 1:20.3-proportion, 3-foot gauge track Size: 40 x 45 feet Theme: none Locale: southwestern United States Era: late 1930s to early 1940s Style: open grid Mainline run: 115 feet Minimum radius: 5′-6″ Minimum turnout: no. 6 Maximum grade: none Originally appeared in the December 2012 […]
Name: Yosemite Valley RR Layout designer: Jack Burgess Scale: HO (1.87.1) Size: 20 x 20 feet Prototype: shortline railroad to Yosemite National Park Locale: San Joaquin Valley and Merced River Canyon in California Era: August 1939 Style: multi-level Mainline run: 112 feet Minimum radius: 22″ with spiral easements Minimum turnout: no. 5 Maximum grade: 2.3 […]
Name: Western Pacific RR Layout designer: Bob Grech Scale: HO (1:87.1) Size: 17′-6″ x 25′-6″ Prototype: freelanced Locale: freelanced Era: 1935 to mid-1940s Style: walk in Minimum radius: 26″ (main line), 24″ (hidden reverse loop) Minimum turnout: no. 6 Maximum grade: 2 percent Originally appeared in the October 2012 issue of Model Railroader. Click here […]
Name: Whiskey Barrel & Gotham Layout designer: M.C. Fujiwara Scale: N (1:160) Size: 2 x 4 feet Prototype: freelanced Locale: mountain railroading Era: 1900 to 1970s Style: island or shelf Mainline run: 9 feet Minimum radius: 9-3/4″ Minimum turnout: no. 4 Maximum grade: none Originally appeared in the September 2012 issue of Model Railroader. Click […]
The layout at a glance Name: Midwest Quarry & Mining Co. Layout owner: Bob Genack Scale: On 2 1/2 (1:48, narrow gauge) Size: 8′-6″ x 12′-0″ Prototype: freelanced Locale: Midwest Era: 1930s Style: L-shaped Benchwork: L-girder and open grid Height: 46″ Roadbed: cork Track: Atlas code 100 Mainline run: 57 feet Minimum radius: 24″ Minimum […]
This Map of the Month was featured in the August 2002 issue of Trains magazine. If ever two railroads practiced seamless service decades before it became a railroad industry buzzword, it would be the Chicago & North Western and the Omaha Road. The Omaha Road, the usual shorthand for the Chicago, St. Paul, Minneapolis & […]
Colorado & Southern narrow gauge 2-8-0s Nos. 70 and 73 cross the high bridge on the Georgetown Loop with seven cars. The engines are moving at only 5 mph due to the frail nature of the bridge on May 14, 1938. Photo by R. H. Kindig […]
Name: Quanah, Acme & Pacific Layout designer: Steven Otte Scale: N (1:160) Size: 5′-9″ x 11′-0″ Prototype: Frisco subsidiary Locale: North Texas Era: early 1929 Style: donut with oNeTRAK modules Mainline run: 46 feet Minimum radius: 11″ Minimum turnout: no. 5 Maximum grade: none Originally appeared in the February 2012 issue of Model Railroader. Click […]
Name: Creamery Junction Layout designer: Michael Tylick Scale: HO (1:87.1) Size: 4′-8″ x 16′-8″ Prototype: Boston & Maine and Boston & Albany Locale: Ware Valley, Mass. Era: variable Style: multi-level Mainline run: 150 feet Minimum radius: 24″ Minimum turnout: no. 5 Maximum grade: 2.6 percent Originally appeared in the December 2011 issue of Model Railroader. […]
Name: Western Electric Empire, City & Suburban Lines Layout designer: Bill Everett Scale: O (1:48) Size: 15′-11″ x 25′-0″ Prototype: Pacific Electric System Locale: freelanced, inspired by Los Angeles area Era: 1920s to 1940s Style: around the walls Minimum radius: 12″ Minimum turnout: no. 2 Maximum grade: 5 percent Originally appeared in the December 2011 […]
Name: London, Midland & Scottish Ry. (LMS) Layout designer: Greg Simpson Scale: OO (1:76 proportion on 1:87.1 HO gauge track) Size: 15 x 20 feet Prototype: (LMS) Locale: England, West Midlands Era: 1900s to 1960s Style: walk-in Mainline run: 100 feet Minimum radius: 18″ Minimum turnout: no. 6 (main), no. 4 (sidings) Maximum grade: 1 […]
