The railway at a glance Name: D & R Railroad Size of Railroad: 60′ x 150′ Scale: 1:20.3 Gauge: 45mm (Nº 1) Era: 1900s-1940s Theme: Chama branch of the D&RGW Railroad Age: 4 years Motive power: Battery-powered locomotives Length of mainline: 1,000′ Maximum Gradient: 3% Type of track: Aristo-Craft brass, code-332 flex track; Parker Company […]
Track plan at a glance Name: Stove Pipe WellsScale: N (1:160) narrow gauge (Nn3)Size: 4′-1″ x 9′-0″Theme: mining short lineEra: 1870s to 1950s, depending upon rolling stock usedStyle: portableMainline run: 34′-6″Minimum radius: 10″Minimum turnout: no. 5Maximum grade: 5 percentOriginally appeared in the December 2006 issue of Model Railroader.Also appeared in 102 Realistic Track Plans.Click on […]
Track plan at a glanceName: Appalachian & Ohio RRScale: O (1:48)Size: 28′-6″ x 56′-0″Theme: Appalachian coal haulerEra: 1969Style: linear walkaroundMainline run: 230 feetMinimum radius: 60″Minimum turnout: no. 6Maximum grade: 2.75 percentOriginally appeared in the May 2006 issue of Model Railroader.Click on the link to download a PDF of this track plan […]
Track plan at a glance Name: Bay Point & DiabloScale: On2.5 (1:48 proportion, 2.5-foot gauge)Size: 11 x 12 feetPrototype: Bay Point & Clayton RREra: Early 20th centuryStyle: around the wallsMainline run: 33.5 feetMinimum radius: 24″Minimum turnout: no. 5(main line), no. 4 (yard)Maximum grade: 5 percentOriginally appeared in the May 2005 issue of Model Railroader. Also […]
Track plan at a glanceName: Burton on TrentScale: OO (1:76 proportion on 1:87.1 HO gauge track)Size: 15 x 21 feetPrototype: London, Midland & ScottishEra: 1920s to 1960sStyle: multiple loops with walk-in aisle and duckunder operating pitMainline run: 126 feetMinimum radius: 18″Minimum turnout: no. 6 (main), no. 4 (sidings)Maximum grade: 1 percentOriginally appeared in the April […]
Track plan at a glanceName: Chesapeake & Ohio Alleghany SubdivisionScale: HO (1:87)Size: 16 x 21 feetPrototype: western end of the Alleghany SubdivisionEra: 1948-1952Style: walkaroundMainline run: 108 feetMinimum radius: 22″Minimum turnout: no. 8Maximum grade: 2.8 percentOriginally appeared in the June 2006 issue of Model Railroader.Click on the link to download a PDF of this track plan […]
Track plan at a glanceName: Alleghany SubdivisionScale: HO (1:87)Size: 22 x 24 feetPrototype: Chesapeake & Ohio Ry.Period: summer 1947Style: walkaroundMainline run: 150 feetMinimum radius: 34″ main line, 28″ branch lineMinimum turnout: no. 6Maximum grade: 1.67 percentOriginally appeared in the February 2005 issue of Model Railroader. Also appeared in 102 Realistic Track Plans.Click on the link […]
Track plan at a glance Name: Cascade County Narrow GaugeScale: On3 (1:48)Size: 26′-0″ x 31′-3″Prototype: Nevada County Narrow GaugeEra: mid-1920s to early 1930sStyle: walkaroundMainline run: 175 feetMinimum radius: 36″Maximum grade: 3.3 percentOriginally appeared in the January 2006 issue of Model Railroader.Click on the link to download a PDF of this track plan […]
Track plan at a glance Name: Central New Mexico Ry.Scale: O scale (1:48 proportion), narrow gauge (On3 and On2.5)Size: 11′-3″ x 17’2″Theme: narrow gauge miningEra: 1905Style: island with an open centerMainline run: 34 feetMinimum radius: 28″Minimum turnout: no. 6Maximum grade: 8 percent on the On2.5 tram lineOriginally appeared in the July 2006 issue of Model […]
Track plan at a glanceName: Central RR Co. of New JerseyScale: HOSize: 9 x 10 feetMinimum radius: 24″Minimum turnout: no. 6Originally appeared in the March 2005 issue of Model Railroader. Also appeared in 102 Realistic Track Plans.Click on the link to download a PDF of this track plan […]
Track plan at a glanceName: City of WauwatogaScale: HO (1:87.1)Size: 8 x 14 feetPrototype: Milwaukee RoadEra: 1945-1965Style: portable islandMainline run: 40 feetMinimum radius: 24″ main line, 18″ industrialMinimum turnout: no. 6 main line, no. 4 industrial tracksMaximum grade: 4 percentOriginally appeared in the December 2006 issue of Model Railroader. Also appeared in 102 Realistic Track […]
Track plan at a glance Name: Crabbitt & Pitchahissee RRScale: HO and HOn3 (1:87.1)Size: 26’0″ x 26’0″Period: 1920Style: walk-inMainline run: 124 feetMinimum turnout: no. 4Minimum radius: 24″Maximum grade: 7 percentOriginally appeared in the April 2006 issue of Model Railroader.Click on the link to download a PDF of this track plan […]
